DUWAI BJ-15A Explosion Proof Non Sparking Connector 300A 4pin Fix Mobile Atex

Name: DUWAI BJ15A Explosion Proof Non Sparking Connector 300A 4pin Fix Mobile Atex
Brand: DOWE
Price: 22.21 USD

Wholesale DUWAI BJ-15A Explosion Proof Non Sparking Connector 300A 4pin Fix Mobile Atex from china suppliers

Brand Name : DOWE

Model Number : BJ-60YT/GZ-4

Certification : CE UL

Place of Origin : China(Mainland),Zhejiang

MOQ : 1

Price : USD22.21/set

Payment Terms : L/C, T/T, , D/P

Supply Ability : 1000pcs per day

Delivery Time : 5-7days

Packaging Details : inner box with carton

Product name : EX-proof connector

Type : BJ-60YT/GZ-4

voltage : 380~500V

current : 60A

model : Fix

core : brass coating silver

Material : aluminium alloy

Sample : free

Contact Now

DUWAI BJ-15A/25A/32A/60A/100A/150A/200A/300A 4pin Fix Mobile Atex Explosion Proof Non-Sparking Connector

DUWAI'completely plastic explosion-protected Ex de plugs and sockets can be used in hazardous areas to connect .

The devices meet all the requirements of IEC and are suitable for use in Zone 1 and Zone 2 applications.

The wide range of high-quality products with self-cleaning lamellar contacts and IP66 protection offers a selection for 16 A, 32 A, 63 A, and 125 A applications.

Ex de and Ex t certified
Easy plug-in and removal
Ambient temperature -40 °C to 45 °C
Type of protection: IP56
Material: Aluminum housings

Main benefits

Safe, durable and reliable
Gas and dust explosion protected

Main features

16 A - 300 A
IP56

Main technical parameters

·Environment temperature:-20℃~+60℃

·Working voltage:380~500VAC

·Working current:15A,25A,32A,60A,100A,150A,200A,300A

·Voltage:2800VAC 50HZ

·Shell protection grade:IP56

Specification	L1	L2	L3	L4	D1	D2	D3	φd±0.07	φd1	φd2	P	Q±0.2
15A	130	55	132	8	φ49	φ33	φ35	13	3	4.5	42.5	34
25A	144	64	142	18	φ61	φ42	φ51	15.6	3.5	4.5	51	42
60A	153	72	145	22	φ64	φ48	φ51	18	5.5	4.5	56	47.5
100A	166	85	173	30	φ79	φ61	φ65	24	7	5.5	70	60
150A	177	92	188	32	φ84	φ65	φ70	27	8.5	5.5	75	64
200A	195	100	199	32	φ90	φ71	φ73.5	30	10	5.5	80	70
300A	200	100	199	42	φ90	φ71	73.5	34.5	12	5.5	80	70

DUWAI BJ-15A Explosion Proof Non Sparking Connector 300A 4pin Fix Mobile Atex
